眼面部防护用品高重物体冲击防护性能测试仪（Eye and facial protective equipment - High weight object impact protection performance tester）
执行标准：
GB14866-2023，GB/T32166.2
Execution Standards:
GB14866-2023，GB/T32166.2
技术参数：
控制系统：PLC;
操作界面：彩色7寸触摸屏，中英文切换；
展开剩余86%工作高度：0-1300mm；设备设计高度1500mm;
头模支架移动距离:左右30mm ,前后20mm
钢球规格:直径22mm ,质量约45g (消防头盔面罩、自吸过滤式防颗粒物呼吸器、 防护面具眼睛)、直径16mm ,重量16g (光学树脂镜片).
冲击高度: 1300mm+10mm (消防头盔面罩、防护面罩眼镜 )、1270-1300mm (光学树脂镜片)。
头模重量: 5kg ,符合GB/T10000的相关规定，可手动旋转头模。
Technical Parameters:
Control system: PLC;
Operation interface: 7-inch color touch screen, switching between Chinese and English;
Working height: 0-1300mm; Equipment design height 1500mm;
Head mold bracket movement distance: left and right 30mm, front and rear 20mm
Steel ball specifications: diameter 22mm, weight approximately 45g (fire helmet face mask, self-priming filter anti particle respirator, protective mask eyes), diameter 16mm, weight 16g (optical resin lens)
Impact height: 1300mm+10mm (fire helmet face mask, protective face mask glasses), 1270-1300mm (optical resin lenses).
Head mold weight: 5kg, in accordance with the relevant provisions of GB/T10000, can manually rotate the head mold.
原理：
眼面部防护用品高重物体冲击防护性能测试仪的工作原理主要基于冲击力学和材料力学。该测试仪通过模拟高重物体（如钢球、石块等）的冲击速度和力量，对眼面部防护用品（如面罩、护目镜等）进行冲击测试。在测试过程中，仪器会记录并分析防护用品在受到冲击时的变形、破裂等情况，从而评估其抗冲击性能。
Principle:
The working principle of the high weight object impact protection performance tester for eye and facial protective equipment is mainly based on impact mechanics and material mechanics. This tester simulates the impact speed and force of heavy objects (such as steel balls, stones, etc.) to conduct impact tests on eye and facial protective equipment (such as face shields, goggles, etc.). During the testing process, the instrument will record and analyze the deformation, rupture, and other conditions of protective equipment when subjected to impact, in order to evaluate its impact resistance performance.
应用领域：
主要用于测试各种眼镜镜片、太阳镜、护目镜、防护面罩眼镜、眼镜等抗冲击性能。广泛应用于相关生产、科研、质量监督检测等单位。
Application Areas:
Mainly used to test the impact resistance of various types of eyeglass lenses, sunglasses, goggles, protective face shields, glasses, etc. Widely used in related production, scientific research, quality supervision and testing units
特征：
冲击高度可调节,并数字实时显示测试高度。
钢球投放器的定位支架采用垂直升降结构，确保始终处于面罩中心位置。
配置专用头模,方便不同大小的头盔进行试验。
头模支架可移动,便于不同大小头盔进行距离的调整。
采用无漏磁式控制方式,瞬间点释放钢珠,自由落体冲击。
配有光学树脂眼镜镜片支架,便于安装镜片(选配)。
Characteristic:
The impact height can be adjusted and the test height is displayed in real-time digitally.
The positioning bracket of the steel ball dispenser adopts a vertical lifting structure to ensure that it is always in the center position of the mask.
Configure dedicated head molds to facilitate testing of helmets of different sizes.
The head mold bracket is movable, making it easy to adjust the distance of helmets of different sizes.
Adopting a leakage free magnetic control method, the steel ball is instantly released and subjected to free fall impact.
Equipped with an optical resin eyeglass lens holder for easy installation of lenses (optional).配资平台实盘
